Scanning the Arena MK Auditorium with NavLive
We took the NavLive Scanner to a fit-out event at Arena MK in the UK, capturing the 2,500m² auditorium and surrounding bar areas in just 11 minutes.
Full 3D Point Cloud Model
The NavLive scanner captures a full 3D point cloud as you walk the site, with all processing handled in real time on the device. It's ready to view in the Portal as soon as the scan is uploaded.
TIP: Click and drag your mouse to explore the 3D point cloud
File Formats:
PCD
E57
LAS
LAZ
Floor Plans
Our on-board AI automatically detects walls to generate an initial floor plan, which can be edited directly in the NavLive Portal after scanning. Export a DXF file directly into your BIM software for further refinement.
File Formats:
DXF
Site Photography & Building Schedules
Rewalk the scan with our SiteView tool, viewing every photo captured automatically along the scan path alongside a first-person 3D point cloud for extra reference. Building schedules place photos of windows and doors at the exact position on the plan from which they were taken.
File Formats:
SiteView
JPG
About the NavLive Scanner
Capture Existing Conditions in a Single Site Walk to RICS-Grade Accuracy
The data for all scans on this page was captured using the NavLive handheld scanner. A single operator simply walks through the building once and NavLive captures everything needed to create a complete digital record of the existing conditions, processing the data in real time as you scan.
- Capture up to thousands of square metres in minutes
- RICS-grade accurate point clouds
- Lightweight handheld scanner with no tripods or targets required
- Real-time processing without any lengthy cloud processing before review
- Designed for architects, surveyors, engineers and contractors
